Hose Crimping Machine HZ300
We are Manufacturer, Supplier, Exporter of Horizontal Hose Crimping Machines, Horizontal Crimping Machines, Hydraulic Hose Crimping Machines and our set up is situated in Pune, Maharashtra, India.
- “ANISH” HZ-300 Horizontal Hose crimping machines can extend their working range of Re-forced Hose Pipes from 6 mm to 50 mm diameter (Nominal bore).
- The machine is also provided with replaceable Pre-crimping tools.
- All the operational features are identical to that of the previous model Hz-260.
- Φ17, Φ20, Φ24, Φ28, Φ32, Φ39, Φ45, Φ50, Φ55, Φ63, Φ69, Φ75, Φ88.
- Maximum crimping Size 3″ 1-1/2″ I.D. Hose with 6 spirals
- Maximum crimping Size 2″ I.D. with 4 spirals.
- Hose feeding either from front or rear end of the machine.
- Electrical setting device / mechanical setting devices for Crimp depth.
- Operation with Push Button Control.
- Standard 3 phase motor. (single phase motor on request)
- Crimping and die retraction with hydraulic cylinders.
- Setting of Crimp depth within 0.1 mm.
- Optional Die Sets : 100
- Special Die Sets : Any size beyond this but less than 85.
- Foot Switch Control.
- Microprocessor based controls with programmable settings
